With the oil crises and pollution concerns, the 1970s defined an era of turbulence in the automotive industry that spared few upscale manufacturers. In this uncertain economic climate, Mercedes-Benz launched the W116 with high expectations from the public: it replaced the popular and robust W108 and W109 series.

The W116 is one of the most polarizing Mercedes-Benz series ever produced: W108 owners generally regard it as the car that solved the safety and environmental issues faced by early-1970s cars while others seem to prefer the more-evolved W126 that came after.

In response to the decade's constantly changing government requirements, Mercedes was forced to use the W116 as a rolling test-bed for changing engine specifications, suspension tuning and, particularly, emissions technology, to adapt to changing U.S. emissions requirements.

Examples of these adaptations include the catalytic converter (1975 U.S. models), automatic climate control (1976, all models), the four-wheel selective leveling system (1976 6.9), the turbodiesel engine (1978) and K-Jetronic fuel injection (1976, all gasoline V-8 models). The darkest days of the model are exemplified by the 1975 and '76 280S, which relied on a low-compression version of the M110 twin-cam six to generate 120 horsepower while returning a paltry 12 mpg at any speed above 70 mph.

But even cars like the 280S have found a niche today; many W116 fans are new to classic-Mercedes-Benz ownership. They often approach the W116 with fresh eyes that find the model to be charming and elegant in comparison with modern cars.

In the end, the W116 was given a new lease on life with the introduction of the endearing 300SD. The turbodiesel era of Mercedes automobiles had finally arrived; as a result, most of the W116s available today are diesels. But don't worry. There are still plenty examples of the 280SE, 450SE and SEL available – even the 280S – for you to choose.

The 450SEL 6.9 was the top W116 model, offering unmatched luxury and power with a wheelbase extended 4 inches, a hydropneumatic suspension system with level control and a 6.9-liter V-8 engine. All W116 models shared restrained styling, generous interior space, a comfortable ride and industry-leading active and passive safety features, including the first production ABS system, co-developed with the Robert Bosch Company. Inside, a padded dashboard, deformable switches and a padded steering wheel provide advanced crash protection.

Background

Initial W116 models, including the 280S and SE and the 350SE were introduced in Europe in September 1972 for the 1973 model year; there never was a 1972 version. The predecessor W108 was phased out at the same time, a rare instance of a model-year gap. An early U.S. road-test model was built for Road & Track magazine in February 1973. By April 1974, the 450SE and SEL, 350SE and SEL and 280SEL had been introduced in Europe. The only models reaching the United States were the 450SE and SEL. The rest were destined for Europe until 1975, when the 280S was introduced in America.

In 1976, all V-8 models were updated with hydraulic valve tappets and K-Jetronic injection. The automatic climate-control system that Mercedes-Benz adapted from Chrysler was also standardized on U.S. models. This system has somewhat soiled the reputation of the 1976 and later W116s because it is difficult to repair.

The 450SEL 6.9, usually referred to simply as the "6.9" was also introduced as a 1976 variant in Europe; an American version followed in 1977. The 280S was replaced in 1977 by the stronger, faster 280SE (the United States never received a long-wheelbase version). In 1978, interest in the model was revived by the new 300SD – not as fast as a 450SEL – but still capable of 25-30 mpg. Production of this model continued into August 1980 with nearly 29,000 units produced.

The majority of W116s were phased out in Europe during the 1979 model year, but American market production continued into 1980.

Few if any major model changes occurred during the life of the W116. One huge change included the 1974 model year update (implemented in summer 1973) to larger bumpers to meet (then) recently instituted federal standards that required vehicles to withstand up to five-mph collisions without damage to lights, safety equipment or engines. The next major update occurred in 1976 with engine and climate-control changes.

Today, the W116 has found a well-deserved niche with enthusiasts who are new to classic Mercedes-Benz ownership. Bruno Sacco's angular design appeals to the eye of a younger generation that appreciates the build quality and hipness of these cars – even when they sometimes don't fully understand them. The 6.9 and 300SD have cult followings; the 6.9 in particular has begun to earn an especially enthusiastic reception in the last few years.

Reasons to buy a W116

Mechanical:

• Consistent build quality, even on 1975-76 emissions-era cars.
• Mechanical robustness.
• Long driveline and suspension life.

Structural:

• Chassis can absorb a 40-mph impact without cabin intrusion.
• Comfortable interiors allow for extended trips.

Personal:

• Indie cred… if that sort of thing matters to you.
• Attractive styling, although this is subjective.
• Because you already own a W108/109 and a W126.
• Increasing interest from the collector-car community.
• Easily available service literature and mechanical-parts supply.
• Cheaper to purchase and service than a W108 or W109.
• The W116 300SD is an amazing car.



Reasons not to buy a W116

Mechanical:

• Poor fuel economy on gasoline models.
• Emissions headaches on 1975-76 U.S. market examples.
• Automatic climate-control systems are challenging to repair.

Interior:

• Difficulty finding interior and exterior parts.

Personal:

• Not as developed as the W126 that replaced it.
• Difficult sellers with unrealistic expectations.



Checkpoints

Mechanical:

• Front and rear glass seals often need replacement.
• Transmission leaks at the front seal.
• Driveshaft flex discs, engine mounts, rubber driveline parts.
• Leaking steering gear boxes.
• Play and noise in steering column means bad steering coupler.
• On 6.9s, test-drive to check hydraulic suspension for leaks and bouncing. Rebuilding a 6.9 hydraulic suspension is expensive.
• Worn front control-arm bushings, ball joints, steering linkages and upper control arms require replacement.
• Rear subframe bushings and rear control arms worn/rusty.
• Engines, whether M110, M116, M117 or OM617, are fairly sturdy and long-lived; V-8s may need timing chains and upper chain rails. The 6-cylinder engines may require a gasket between the cylinder head and camshaft-carrier bearing box. With the exception of V-8 engines after 1975, all engines require regular valve-lash adjustment. Oil consumption should be assessed; valve guides commonly wear on gasoline engines.

Structural:

• Trunk wells often rust due to water collection.
• Floor pans rust, especially in areas low enough to collect water.
• Rust can permeate several other areas: at extremities of firewall, around the fuse box; sunroof tray (if sunroof-equipped); door bottoms; rocker panels (common in coastal or rust-belt cars); shock towers; under brake booster and climate-control servo on cars that have not been cleaned or garaged; in the cowl under cowl-vent grille due to drainage issues.

Interior:

• Interior panels, such as door panels, roof rail panels, center console, dash, etc., are prone to fading and cracking. These are not available new and used parts are difficult to source.
• Automatic climate-control systems usually need some kind of repair; servos are still available new, as are vacuum actuators.
• Woodwork is often lackluster, and refinishing is a challenge; it's difficult to remove the wood from the car.
• If front/rear seats look deflated, excelsior pads are deteriorated – typical on early W116s – replacements cost over $3,000.

Personal:

• Look for a seller with realistic price expectations.



The bottom line

The W116 is slowly gaining recognition. While these cars often require a good amount of work to get in order again, a sorted model can be a delight to drive. And the 280S – with its catalytic converter and Solex carburetor – can still be a fun car to own and drive regularly. Like all classic Mercedes-Benz vehicles, these are usable cars with excellent braking and handling; driving doesn't feel like a chore.

While these fine automobiles are outstanding examples of intrinsic value, their commercial values don't yet reflect the respect the cars deserve: This makes them a difficult sell for a profiteer. But a star-struck buyer will appreciate that the W116 is still one of the best-kept secrets in the world of classic Mercedes-Benz cars.
